| Name: | LZJ-6D Operation Microscope with Monitor |
|---|---|
Product Description
LZJ-6D Operation Microscope
The model LZJ-6D operation microscope is our the latest researched product for ophthalmic surgery. Equipped
with the parallel optical route way and with advanced motorized 5-step zoom system. The assistant scope have
three ranges of magnification, and it can be installed in right or left within 90°. This instrument may adopt CCD or
DC by attachment. Camera and presenting facilities are useful for teaching and storing information.
This is the most advanced operation microscope for ophthalmology in domestic markets, and can meet all kinds of ophthalmic surgery.
Features
Ø The main adopts 5-step magnification zoom system, 3.5X , 5.4 X , 8.5X, 13.5X, 21X, its and assistant scopes share the construction of the same light route, and zero degree between them.
Ø Light systems is equipped with retina protection device, red reflex intensifier, filter of infrared.
Ø The assistant scopes possess the step magnification of 6X by hand wheel, also, it can revolve round the main scopes within 90°.
Ø X-Y system with push button, and the moving range of X-Y:40mm.
Ø Equipped with motorized bending or lifting adjustment construction, it is convenient for doctor to operate the instrument.
Parameters:
With retinal protection, Newly designed gas spring balanced rack | |
View angle of Eyepiece | 45° |
Field of View | Φ68, Φ43, Φ27.5, Φ17.5, Φ11mm |
Main microscope | 5 steps |
Magnification of Main microscope | 3.5X , 5.4 X , 8.5X, 13.5X, 21X (0.4~0.25/step) |
Magnifications of Main scope Eyepiece | 10×/22B |
Magnifications of Assistant scope Eyepiece | 12.5x/18B |
Working Distance | 200mm |
Adjustable Range for Pupil Distance | 55mm ~ 75mm |
Illumination Type | 0° + 6°coaxial cold fiber optic lighting |
Illumination Source | 15V/150W cold fiber optic lighting |
Maximum illuminance of the object surface | ≥80000LX |
Reaching Radius of Arm | 1200mm |
Adjustable Vertical Range | 850mm~1350mm |
Bracket lifting range | Spring arm adjustment range 250mm |
Foot-controlled electric fine focusing system | Range:40mm |
Range for X-Y | 40mm(continuously adjustment, and one key to zero) |
Microscope front and rear adjustment angle | -5°~10° |
Voltage | AC220V±10%V/50Hz±1Hz |
Option: Video camera system
Interface of video camera: CCD optical adapter
Video camera: Sony series video camera
Display: 23 inch brand HD display
Accessories: HDMI HD data line, built-in power supply, no need to charge , HD memory card
